Gigabyte
SKU:GV-N5090GAMING OC-32GD
Couldn't load pickup availability
2550 MHz (Reference card : 2407MHz)
NVIDIA Blackwell Architecture
Max AI performance with FP4 and DLSS 4
Optimized for neural shaders
Built for Mega Geometry
The WINDFORCE cooling system delivers exceptional thermal performance through a combination of cutting-edge technologies. It features server-grade thermal conductive gel, innovative Hawk fans with alternate spinning, composite copper heat pipes, a large vapor chamber, 3D active fans, and screen cooling.
The GAMING series draws the concept from mech warriors, blending the futuristic armor with mechanical aesthetics to deliver exceptional protection and powerful durability. It goes beyond mere appearances and functionality, offering a profound interpretation of futuristic technology.
Like armor, the exterior features a multi-layered structure combined with varied surface material finishes.
Unique textures cover the curved surface, paired with the layering of appreance that give the GAMING design a strong armor-like identity. Every detail highlights a sturdy image and accentuates mechanical aesthetics.
The legendary three-ring lighting provides excellent visual enjoyment. You can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER.
Featuring a power armor design with a sliding side plate, allowing users to customize their build to match their unique style.
This animation is for illustrative purposes only. Actual product appearance may vary.
The reinforced metal backplate with a bent edge, securely fastened to the I/O bracket, provides exceptional structural integrity.
The factory default setting is Performance mode, which provides users with the best performance. However, switching to silent mode will enjoy a quieter experience.
When experiencing any power supply abnormality, the indicator will alert gamers by flashing light.
Our newly designed VGA holder offers dozens of customizable mounting options, ensuring your graphics card is securely supported and prevents sagging. Its sleek design allows for discreet installation, enhancing the overall aesthetics of your system.
GIGABYTE offers the best power supply solutions for your graphics cards. You can choose either the AORUS series or the UD series to power your graphics card.
GIGABYTE CONTROL CENTER (GCC) is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
| Processor | |
|---|---|
| Graphics processor family | NVIDIA |
| Processor frequency | 2550 MHz |
| Parallel processing technology support | Not supported |
| Maximum displays per videocard | 4 |
| CUDA cores | 21760 |
| CUDA | Yes |
| Maximum resolution | 7680 x 4320 pixels |
| Graphics processor | GeForce RTX 5090 |
| Memory | |
| Discrete graphics card memory | 32 GB |
| Memory clock speed | 28000 MHz |
| Data transfer rate | 28 Gbit/s |
| Memory bus | 512 bit |
| Graphics card memory type | GDDR7 |
| Ports & interfaces | |
| HDMI version | 2.1b |
| HDMI ports quantity | 1 |
| DisplayPort version | 2.1b |
| DVI-I ports quantity | 0 |
| DVI-D ports quantity | 0 |
| DisplayPorts quantity | 3 |
| Interface type | PCI Express x16 5.0 |
| Video | |
| DirectX version | 12.0 |
| OpenGL version | 4.6 |
| HDMI version | 2.1b |
| Dual Link DVI | No |
| CUDA cores | 21760 |
| Performance | |
| DirectX version | 12.0 |
| OpenGL version | 4.6 |
| Dual Link DVI | No |
| TV tuner integrated | No |
| Warranty period | 4 year(s) |
| Overclocked (OC) edition | Yes |
| Design | |
| Number of fans | 3 fan(s) |
| Illumination colour | Multi |
| Illumination | Yes |
| Cooling type | Active |
| Form factor | Full-Height/Full-Length (FH/FL) |
| Product colour | Black |
| Number of slots | 2 |
| Cooling technology | GIGABYTE WINDFORCE 3X |
| Power | |
| Supplementary power connectors | 1x 16-pin |
| Minimum system power supply | 1000 W |
| Weight & dimensions | |
| Number of slots | 2 |
| Weight | 2 kg |
| Height | 152 mm |
| Depth | 70 mm |
| Length | 342 mm |
| Technical details | |
| Cooling type | Active |
| Form factor | Full-Height/Full-Length (FH/FL) |
| Product colour | Black |
| TV tuner integrated | No |
| Warranty period | 4 year(s) |
| System requirements | |
| Minimum system power supply | 1000 W |
| Packaging data | |
| Package type | Box |
| Package width | 264 mm |
| Package height | 105 mm |
| Package depth | 427 mm |
| Package weight | 3 kg |
| Cables included | Power |
| Packaging content | |
| Cables included | Power |
| Quick installation guide | Yes |
| Logistics data | |
| Products per shipping (inner) case | 1 pc(s) |
